Industrial-Grade High Precision with Dual Detection for All Fastening Scenarios

It delivers ±1% torque accuracy in both clockwise and counterclockwise directions, meeting strict industrial fastening quality standards. All models are equipped with an angle sensor + gyroscope for angle measurement and support residual torque detection. Multiple fastening strategies are available: torque control, torque+angle monitoring, angle+torque monitoring, torque+angle step control and inspection mode, fully covering diverse quality control needs for precision assembly.

Full Wireless Data Traceability with OP Protocol for Production Line Integration

It supports real-time wireless fastening control and full data traceability. Compatible with the industrial Open Protocol (OP), it seamlessly integrates with factory MES and quality management systems. On-board memory stores up to 1200 fastening results and 31 torque curves, meeting data retention needs for batch operations and enabling fully traceable fastening processes and quality accountability.

 Aerospace-Grade Lightweight Construction for Easier High-Torque Operation

The wrench shaft is built with aerospace-grade high-strength material, ensuring structural rigidity, torsional strength and durability while significantly reducing overall weight. The 1000Nm high-capacity model weighs only 4.1 kg, much lighter than traditional torque wrenches of the same class. It reduces fatigue during prolonged handheld operation and greatly improves maneuverability and operating comfort.

Dual Wireless Solutions for Diverse Production Line Layouts

Two wireless solutions are available: LoRa and WiFi versions, with corresponding models for each torque range. The LoRa version achieves 50m obstacle-free communication range with strong anti-interference performance, suitable for open workshop scenarios. The WiFi version supports dual-band 2.4GHz/5GHz for direct connection to existing factory WiFi networks. Both 1-to-1 standalone and 1-to-8 network configurations are available to meet needs of single-station and multi-station networking.

 Multi-Mode HMI Alerts for Efficient & Accurate Operation

Equipped with a 130×42 color TFT LCD screen for clear, readable data display. It adopts triple feedback via tri-color ring LED, vibration and buzzer, delivering instant alerts when target torque/angle is reached. Operators can judge fastening status without staring at the screen, effectively preventing under-tightening and over-tightening, and greatly improving work efficiency and fastening accuracy.

 Professional PC Software for Full-Process Digital Management

It comes standard with professional PC management software, supporting tool parameter programming, fastening data filtering, and torque curve acquisition & analysis. Up to 100 fastening programs can be preset and switched with one click to fit different workstation requirements. It supports integrated serial port for barcode scanner connection, enabling bound management of tools, workpieces and operators, and adapting to quality management systems of digital factories.
