[Precision] Full-range, high-precision performance compliant with international standards：

Achieves ±5% 6σ accuracy across the entire 0.02~480Nm torque range, controlled by self-developed high-precision algorithm.Passes hard and soft connection precision tests, fully complies with ISO5393 international standard, with CMK>1.67 under ±5% process conditions

[Speed] Multi-strategy, multi-tasking capabilities to boost production efficiency：

Supports up to 16 tightening steps, flexibly adapts to complex process requirements.Provides multiple tightening strategies including torque, angle, slope, corner, speed holding, delay waiting, yield point, etc., with preset templates for one-step, two-step and self-learning programming.Supports 254 Psets and 254 Jobs, with up to 254 group tasks and 15-step sub-tasks, meeting the tightening needs of multi-variety and multi-process production.Equipped with graphical task management (optional), with intuitive guidance interface to prevent misoperation.

[Smart] Full process traceability, digital management：

Acts as a tightening central hub, supports activating tools via barcode, bus, I/O, Modbus, etc.Global monitoring of the entire tightening process, real-time recording and monitoring of torque, angle, speed, pass rate and other data.Supports real-time data upload to MES system, with local storage of 500,000 tightening results and 5,000 tightening curves, supporting superposition analysis of up to 50 historical curves.Real-time statistics of Pset/Job/task management data and pass rate, facilitating quality analysis and process optimization.

[Reliable] Comprehensive error prevention to ensure tightening quality：

Full-process data monitoring during tightening, timely detection of abnormal problems such as floating nails, slipping teeth, missing tightening and wrong tightening.Dual qualification judgment via sensor and current, adding locking to ensure tightening qualification.One-click start of failure monitoring mode, automatic alarm for floating nails, slipping teeth and repeated tightening errors.Hierarchical assembly process authority management, requiring password input for debugging interface to prevent unauthorized operation

[Convenient] Convenient and flexible to use; simple to deploy：

Supports multi-barcode configuration, binding tightening results to workpieces, jobs and Psets, standardizing the entire process and avoiding manual misoperation.Excellent human-computer interaction with 10.1-inch touch screen, supporting fast system parameter setting, program viewing, breakpoint resume and information loss prevention.5 start modes available: handheld or machine-mounted, supporting trigger, self-timed, Modbus_TCP and custom protocols.Supports hot-swappable cables (5m/10m/15m/20m optional), with quick expansion ports for inner flower wrench, quick change chuck, eccentric head, opening and closing head and other external modules.Rich communication interfaces: bus, TCP/IP, Modbus_TCP, Http, supporting expansion of digital I/O interfaces; easy peripheral connection, optional barcode scanner, positioning force arm, screw feeder and other equipment.
