Patented Disposable Material Path (DMP) Design:

AT-2000S is an independently developed patented dispensing valve with one-time material path technology.Adopts disposable feeding channel design, maintains dispensing accuracy for a longer time and eliminates cross-contamination.

Ultra-fast Maintenance & Zero Downtime:

Equipped with hinged door design, can be easily opened to remove the disposable feeding channel.Complete replacement can be done in a very short time even on the production line, no need to clean or turn over the valve, no impact on normal operation.

Built-in Heating Function for High Viscosity Fluids:

Optional heating function, improves fluidity of high viscosity glues when heated, ensuring more stable and consistent glue output.Perfectly solves the problem of difficult dispensing of ultra-high viscosity materials such as solder paste and red glue.

High-quality Wear-resistant Screw & Long Service Life:

Feeding screw is made of UV-compatible Delrin material, sourced from strict high-quality suppliers to ensure product quality.Optional tungsten steel screw for more demanding wear resistance requirements, customized according to customer needs.

Suction Function & Low Wear Design：

Built-in suction function eliminates liquid accumulation in the valve body, reduces motor wear and greatly extends the service life of the valve.No need for motor reverse function, simplifying control system and improving operation stability.

Multiple Screw Specifications & Flexible Configuration：

Three screw pitch options are available: AT-P6 (4mm pitch), AT-P8 (3mm pitch) and AT-P16 (1mm pitch).All pitch types are equipped with available or special extension rods to meet different dispensing process requirements.

Dedicated Controller & Multiple Operation Modes：

Equipped with dedicated screw valve controller, can freely adjust cycle dispensing or line drawing mode, as well as suction time.Maximum working frequency up to 400+ times/minute, fully meeting high-volume continuous production requirements.
