Ultra-high Speed Non-contact Jetting:

Maximum working frequency up to 1000Hz, instantaneous highest frequency 1500Hz, greatly improving production efficiency.Non-contact jetting mode eliminates Z-axis movement, avoids contact damage to delicate workpieces, and enables stable dispensing on uneven surfaces such as flexible circuit boards.

0.3nl Ultra-precision Micro Dispensing:

Adopts advanced piezoelectric drive technology, ensuring 99% jetting accuracy and consistent dispensing quality.Achieves ultra-fine dispensing effect: minimum line width 0.17mm, minimum dot diameter 0.15mm, minimum single point volume 0.3nl, perfectly meeting the strict requirements of microelectronic precision manufacturing.

Modular Design, Low Maintenance Cost:

Adopts split modular structure: fluid contact part is replaceable channel module, non-contact part is reusable valve body module.Quickly replace channel modules to adapt to different dispensing processes; unique quick-disassembly structure for feed components, less sealing consumables, simpler and faster maintenance.

Wide Viscosity Adaptability + Intelligent Heating:

Applicable viscosity range covers 0-200000cps, compatible with adhesives, lubricants, water solvents, molten polymers and other industrial fluids.Equipped with first-level nozzle heating device, temperature adjustable from 20℃ to 120℃, maintains glue at constant temperature to ensure optimal jetting performance.

Intelligent Touch Screen Control System:

Touch screen integrated control for piezoelectric jet valve and dispensing system, supports MES system docking, powerful function, safe and reliable.Graphical operation interface, system components and control functions are displayed intuitively, reducing operator training cost.

Universal Platform Compatibility:

Can be seamlessly matched with any automatic dispensing platform on the market, flexible integration into various automated production lines.Nozzle diameters are available in full series from 40μm to 500μm, including flat jet type, needle type and extended type to meet different process requirements.
