Two-stage Precision Heating System:

Adopts two-stage heating design with independent glue barrel heating module and nozzle heating module, temperature adjustable from 20℃ to 220℃.Glue barrel heating module carries glue barrel and one-stage heating to complete initial preheating of glue; nozzle heating maintains constant temperature at the jetting end, ensuring optimal fluidity of hot melt adhesive.Supports 30CC, 100CC and 300CC different volume hot melt glue cartridges, widely adapting to various production capacity demands.

0.3nL Ultra-precise Jetting Performance:

Jetting volume can be accurately controlled to 0.3nL, dispensing consistency up to 98%, ensuring stable and uniform glue output per cycle.Achieves ultra-fine hot melt adhesive jetting process: minimum line width 0.17mm, minimum dot diameter 0.15mm, perfectly meeting the requirements of micro precision dispensing.

High-speed Non-contact Jetting:

Maximum dispensing frequency up to 1000Hz, instantaneous highest frequency 1500Hz, greatly improving production efficiency.Non-contact jetting mode avoids Z-axis movement, eliminates contact damage to delicate workpieces, and enables stable dispensing on uneven surfaces.

Fully Modular Design, Easy Maintenance:

Consists of glue barrel heating module, pressure cap module, nozzle heating module, flow channel module, valve body module and heat dissipation module.Adopts split modular structure: fluid contact part is replaceable flow channel module, non-contact part is reusable valve body module.Quickly replace modules to adapt to different processes; simple disassembly and assembly, low maintenance cost, short downtime.

Intelligent Touch Screen Control System:

Touch screen integrated control for jet valve and dispensing system, supports MES system docking, powerful function, safe and reliable.Graphical operation interface, system components and control functions are displayed intuitively, reducing operator training cost.

Universal Platform & Nozzle Compatibility:

Can be seamlessly matched with any automatic dispensing platform on the market, flexible integration into various automated production lines.Nozzle diameters are available in full series from 40μm to 500μm, including flat jet type, needle type and extended type to meet different process requirements.
