Built-in Strong Suction Anti-drip Design：

Adopts advanced suction type sealing structure, generates negative pressure instantly when the valve closes, sucking back residual glue at the nozzle.Completely eliminates common problems such as glue dripping, stringing and hanging glue, ensuring clean and tidy dispensing surface and improving product yield.

Small Flow Precise Glue Control：

Minimum dispensing volume reaches 0.1g, maximum flow rate up to 5L/min, enabling stepless adjustment of glue output.Stable and consistent glue output per cycle, perfectly meeting the requirements of precise small-flow dispensing processes.

Wide Medium-high Viscosity Fluid Adaptability：

Suitable for fluid viscosity from 1000CPS to 5000CPS, covering most medium-high viscosity industrial fluids.Compatible with various materials such as silicone, epoxy resin, grease, anaerobic glue and hot melt adhesive.

Corrosion-resistant Wetted Parts：

Wetted parts adopt high-quality SUS304 stainless steel and AL6061 aluminum alloy materials.Excellent corrosion resistance and wear resistance, suitable for long-term contact with various chemical fluids, extending service life.

High-speed Stable Operation：

Maximum movement speed reaches 100 cycles/min, with fast pneumatic response and no lag phenomenon.Working pressure above 0.6MPa, ensuring stable and reliable operation in continuous high-speed production environments.

Ultra-lightweight Compact Design：

Ultra-compact size with dimension of Φ25×163mm, weight only ≈130g, extremely saving installation space and reducing equipment load.Equipped with standard IN.OUT PT1/8 pipe connection ports, easy to install and disassemble, compatible with most automatic dispensing machines.
