MUTHEL BM-L/BM-LP CNC Brushless Torque Wrench | 100-10000Nm ±5% Digital Display High Torque Tool-Digital Display Brushless Charging Torque Wrench
BM-L/BM-LP Numerical Control Brushless Charging Torque Wrench covers 100-10000Nm ultra-wide torque range with 0.75"/1"/1.5" drive heads. It features 0.96-inch LCD digital display, ±5% torque accuracy (±2% repeatability), brushless motor maintenance-free design, high-capacity air-cooled lithium battery (5.2/8.0AH) with fast charging, and supports angle function, USB log reading, overheating protection and user authority management. Ideal for wind power, petrochemical, bridge steel structure, heavy machinery and shipbuilding industries requiring high-precision high-torque tightening
- Product Details
- Technical Specification
- After-sale service
CNC Digital Display Precise Torque Control, Industry-leading Accuracy：
0.96-inch LCD digital display, real-time display of torque value, working status and fault information.Supports digital torque adjustment, 1-99 gear adjustment or arbitrary torque setting within the range, with 10 groups of programmable preset torque for one-click switching.Industry-leading accuracy: ±5% overall accuracy, ±2% repeatability, ±3% accuracy for -TC models.
High-efficiency Brushless Power System, Maintenance-free & Long-lasting：
Adopts high-efficiency brushless DC motor, no carbon brush wear, zero maintenance, long service life, small size, light weight, low inertia and low vibration.High-precision planetary gear transmission system with 1:1.0 output ratio, high rigidity and high reliability.BM-LH/BM-LPH series with automatic transmission clutch, no-load speed is 4-6 times of standard models; *H high-speed system adopts variable-speed clutch for higher efficiency.
High-capacity Air-cooled Battery System, Long Battery Life & Fast Charging：
Equipped with high-capacity air-cooled lithium battery, supports 5.2Ah and 8.0Ah two specifications, with fast charging technology.Battery power monitoring and compensation function ensures stable torque output under different power levels.
Comprehensive Safety & Intelligent Functions, Improve Operation Efficiency：
Built-in overheating temperature monitoring and torque overload limit function, effectively protects equipment and bolts.User authority management (operator/administrator level) prevents misoperation; buzzer prompt function clearly indicates tightening completion.Background torque calibration software compensation function ensures long-term accuracy stability; anti-reaction force arm locking realizes unloading function.
Rich Optional Configurations, Adapt to Diverse Needs：
Optional angle function, supports local log and USB log reading (-P models), convenient for data traceability and quality management.Standard compliant counterweight arm, customizable counterweight arm available; supports installation of hoisting systems for safer high-altitude operations.Complete model range, covers 100-10000Nm torque range, provides 0.75"/1"/1.5" drive heads to meet various tightening requirements.
This product supports bulk orders and OEM/ODM customized services with factory direct prices.We can provide customized configurations such as torque range, drive head type, battery capacity, angle function and appearance according to customer requirements.
Adopts high-quality industrial-grade components and precision manufacturing processes, with stable quality and guaranteed delivery.We also provide complete operation training, calibration services and long-term technical support services.
