Dedicated Screw Locking Robot Control System：

Perfectly combines SCARA robotic arm control system and screw tightening control system, equipped with large-size LCD programmer.Chinese programming interface, simple and easy to understand, greatly reducing operator training time.

Powerful Software Function & Intelligent Positioning：

Supports CCD visual guidance positioning, automatically compensates for coordinate deviation, effectively solving assembly errors caused by fixture or product position differences.Supports CAD file import for screw hole coordinate programming, automatic path optimization and custom path functions, greatly shortening programming time.

Intelligent Servo Screwdriver with Full Data Traceability：

Adopts multi-stage torque automatic switching tightening process control, supports real-time feedback and monitoring of torque curves and data.Supports screw tightening data storage, recording, uploading and querying, custom format information transmission, and perfect docking with MES system, which is essential for smart factories.

Ultra-high Efficiency & Wide Compatibility：

Fastest tightening speed reaches 1 second per single screw, tightening yield up to 99.9%.Integrates multiple screw tightening processes, customizable torque, number of turns, rotation speed, tightening time, etc.Compatible with air-blowing, air-suction and blow-plus-suction screw feeding modes, suitable for M0.8-M6.0 screws of various specifications.

Rich Expansion Interfaces & Online Calibration：

Supports upper and lower computer linkage operation, RS485, TCP and other multi-protocol communication and I/O interaction functions.Reserves general input and output I/O communication ports to support external application expansion.Optional Jishou online torque tester can realize online automatic torque calibration test.
